4-10 Media Handling and Storage
6. To take up any ribbon slack, rotate the top of the take-up spool’s
wheel (that is, the front wheel) towards the back of the imager,
as shown in the following figure.
NOTE:
Do not use the supply spool (rear) wheel to take up ribbon slack. This would cause
spent ribbon to be reused.
Take-up
spool wheel
Rotate take-up
spool toward
back
Supply spool wheel
(Do not use this wheel)
3
