12-16 Troubleshooting
`äÉ~êáåÖ=~=g~ã=Ñêçã=~=`~ëëÉííÉ
NOTE:
When a jam occurs, the imager disengages all motors to allow you to safely pull out
the sheet.
1. Gently pull out the supply cassette indicated in the message on
the Status screen.
2. Check to see if the sheet is sticking out from the cassette or the
supply slot.
•
If the sheet is sticking out from the cassette or the supply slot,
pull it out gently; then go to step 8.
•
If the sheet
IS NOT
sticking out from the cassette or the supply
slot,
go to the next step.
3. Open the top cover (which has already been partially opened by
the imager).
WARNING With the top cover open, touch only those internal components that
are colored green (refer to the figure on page xxxii). Remove rings, ties, jewelry,
and other items, and tie back hair, so that they do not fall into or get caught in
the imager.
3
8
To clear a jam
indicated by
“Clear jam
from cassette
X
To Next Page
