Codonics Horizon - Control Panel Keys

3-16 Basic Imager Operations
`çåíêçä=m~åÉä=hÉóë
The following table describes the control panel keys. Note that the
control panel keys have backlighting:
• A key is backlit when it is enabled and functional within the
current state of the imager.
• A key is not backlit when it is disabled, given the imager’s
current state.
Table 3-4. Control Panel Keys
Key Description
key
Power key. When pressed, Power menu displays on the
control panel display, allowing you to shutdown or reboot
the imager.
key
Displays the Main Menu on the control panel display, or
exits the menus and redisplays the Status screen. If you
made a change without first saving it, you will be prompted
as to whether you want to save your changes.
The Main Menu includes options that are typically
performed by normal operators.
key is pressed and
held, then
simultaneously the
key is pressed
Displays the additional administrative options in the menus.
and keys
With menu options displayed, these keys scroll the selector
arrow up and down through the menu options. Scrolling
down past the last option wraps around to the top of the
option list. Scrolling up past the first option wraps around to
the bottom of the list. To move the selector arrow rapidly
through available options, press and hold either of these
keys.
When entering data, these keys increment or decrement
the characters in the change brackets. To cycle rapidly
through available values, press and hold either of these
keys. If you reach the end of the value range, there is a
slight pause, then the value at the other end of the range
displays.
