Codonics Horizon - Reinstalling Media Guides

12-22 Troubleshooting
oÉáåëí~ääáåÖ=jÉÇá~=dìáÇÉë
When clearing sheet jams, the media guides could accidently come
out of their slots.
1. Slide the media guide into the imager through the cassette slots,
as shown in the following figure.
Media
guides
8
To reinstall the
media guides
