3-4 Basic Imager Operations
lÄëÉêîá åÖ=íÜ É=fã~Ö ÉêÛë=léÉê~íáåÖ=pí~ íìë=
áå=íÜÉ=pí~íìë=pÅêÉÉå
The Status screen allows you to observe the imager status. The top
portion of the Status screen—the Supply window—displays the
status of the three supply cassettes and whether a color ribbon is
installed. The bottom portion of the screen—the Status window—
displays printing status messages and the imager’s operational state.
Supply CMY
1: 8X10 DV Blue 53
2: A CV Paper 100
3: 14X17 DV Blue 76
Status OK
Sheets queued: 3
Indicates that color ribbon
is installed and its status
Supply window: Indicates
status of supply slots
Number of sheets left in
cassette
Status window: status
messages displayed here
Operational state (OK,
ALERT, or FAULT)
When activity occurs, each
supply entry toggles with
activity status related to
cassette (processing, printing,
calibrating, media jam)
