Horizon Imager User’s Manual 3-1
Basic Imager Operations
=P
_~ëáÅ=fã~ÖÉê=léÉê~íáçåë
The following illustrations show the names and locations of the
main imager components.
Names and Locations of the Imager’s Main Components—Front
eçêáòçå=fã~ÖÉê=`çãéçåÉåíë
Control panelTop cover
Smart Card
panel door
Receive
tray 1
Supply
slot 1
Supply
slot 2
Supply
slot 3
Receive
tray 2
Receive
tray 3
