With the imager top cover open or the receive trays removed,
touch only those internal components that are colored green
(shown in the following figure).
Remove rings, ties, jewelry, and
other items, and tie back hair, so that they do not fall into or get
caught in the imager.
Internal Components That Are Colored Green (called out in the
illustration) Are Safe to Touch
Upper fender
releases
(up position)
Top cover releases
Spring-loaded
spindles
Spool wheels
Upper fender
releases
(down position)
Top cover
master
release
Media
guides
Picker
(lift here)
Diverter
