Codonics Horizon - Rear Connectors

3-2 Basic Imager Operations
Names and Locations of the Imager’s Main Components—Rear
Rear Connectors
C
O
N
S
O
L
E
U
P
S
Power rocker switchConnectors
CONSOLE
UPS
Network connector
Speed indicator:
On—100 Mbps
Off—10 Mbps
Activity indicator:
On—Link
Flashing—Activity
Off—No link
Console
(service only)
UPS
(for connection to
UPS serial
control cable)
USB ports
