Horizon Imager User’s Manual 10-15
Preventive Maintenance
6. Wipe around each tire with the platen roller cleaning wipe that
is provided with the Platen and Print Head Cleaning kit.
Note that the cleaning wipe may become discolored.
7. Wait for the pick tires to dry thoroughly.
8. Replace the receive trays and any media cassettes that were
removed.
After a few seconds, the Status screen displays and printing
resumes if jobs are queued.
1. Press the key, and wait until the imager enters the Paused
state.
The Status screen should indicate that the imager is paused.
2. Remove any cassette currently in supply slot 1, and make sure
that the receive trays are in and the top cover is closed.
3. Press the key.
The Main Menu displays.
4. Select the following options:
Utilities
Clean Barcode Reader
Instructions for cleaning the barcode reader are displayed.
CAUTION
Use only the platen roller cleaning wipe when cleaning the pick tires. The
tires could be damaged if you use the print head cleaning wipe.
CAUTION
Do not touch the pick tires (which may be white or green); body oils from
your fingers are hard to remove and could eventually damage the tires.
`äÉ~åáåÖ=íÜÉ=_~êÅçÇÉ=oÉ~ÇÉê=táåÇçï
8
To clean the
barcode
reader windo
PAUSE
MENU
