xxx Preface
Radiated RF Immunity
IEC 61000-4-3
3 V/m
80 MHz - 2.7 GHz
80 % AM at 1 kHz
Proximity fields from RF wireless
equipment
IEC 61000-4-3
Complies
Electrical Fast Transient / Burst
IEC 61000-4-4
AC Port: ± 2 kV, 100 kHz repetition
frequency
SIP/SOP Ports: ± 1 kV, 100 kHz
repetition frequency
Surge
IEC 61000-4-5
Line-to-Line: ± 0.5 kV, ± 1.0 kV
Line-to-Ground: ± 0.5 kV, ± 1.0 kV, ± 2.0
kV
Conducted Immunity
IEC 61000-4-6
AC Port and SIP/SOPs:
3V, 0.15 MHz - 80 MHz
6V, in ISM bands between 0.15 MHz and
80 MHz
80 % AM at 1 kHz
Magnetic Field Immunity
IEC 61000-4-8
30 A/m, 50 Hz or 60 Hz
Voltage Dips
IEC 61000-4-11
0% U
T
, 0.5 cycle at 0°, 45°, 90°, 135°,
180°, 225°, 270° and 315°
0% U
T
, 1 cycle AND 70% U
T
, 25/30
cycles, Single phase: at 0°
Voltage Interruptions
IEC 61000-4-11
0% U
T
, 250/300 cycle
Electromagnetic Immunity Standards and Test Levels: (Continued)
Test / Standard Compliance Level
