Horizon Imager User’s Manual 2-27
Setting Up the Imager
5. Open the top cover by pressing any of the green releases shown
in the following figure.
6. Make sure that the thermal print head has parked. The thermal
print head should be secure with no wobble.
Right
release
Left
release
Master
release
Thermal print
head
Make sure thermal
print head is secure
and does not
wobble
