System sets system protection (commands affecting the system cannot be used).
Syntax: SCPS
·
View displays the current default values for the following:
-
default arm
-
default communication port
-
default system device
-
current protection level
-
current time and date
-
default backup device
-
default PDL2 device
-
current $GEN_OVR increment
-
startup file
-
Software (hour meter): number of operation hours in DRIVE ON.
Options: /4
Syntaxi: SCV
· Win_clear clears the information shown on a window.
Syntax: SCW <window_name>
Input
Force Unforce View
Arm Cntrler Input
Output Total_unf Update_io View_io
The INPUT command displays a menu of commands to control the user inputs. The subcommands can be
used while memory protection is on, but not when system or programme protection is on or when the control
-
ler is in a FATAL state. This is true of all commands except VIEW which can be used in all system states.
Also, the SET INPUT and SET TOTAL_UNF commands must not be active to use this command. If the pro
-
gramming terminal is connected, but not on the cabinet, the FORCE and UNFORCE commands are disabled
from the keyboard of the Screen-keyboard unit.
Each INPUT command displays a submenu to select the type of input as follows:
AIN DIN GIN
Force Unforce View
·
Force simulates the inputs. The physical input is bypassed and the forced value is used. The operator
can choose from the submenu to force analogue (AIN), digital (DIN) or group (GIN) inputs. A particular
input can be specified by its index number. The asterisk cannot be used. A forced value can be speci
-
fied. If no value is specified, the input is forced to its current physical state.
When digital inputs are forced, the forced value can be either C meaning its current physical state, T
meaning TRUE (ON) or F, meaning FALSE (OFF). These options are displayed after the prompt for the
forced value. Select the appropriate value and press the ENTER key.
A digital input that is part of a group of inputs must be forced as a group and not as a digital input. This
command is not allowed in case the command is sent from PCINT or from SYS_CALL and the PTU4
has not been placed in the cabinet.
C3G Plus OPERATOR INTERFACE
07/1200 3-53
SET COMMAND
