FUSES AND PROTECTIONS
FUSES TYPE PROTECTION
F1
250V 0,5A
Normal Blow Fuse Optional RPT Module (Robot)
F2
250V 0,7A
Normal Blow Fuse Optional RPT Module (Robot)
F1
125 V/10kA 5A
Quick-Acting-Fuse 24 Vdc output SIM module
F1-F2
125 V/10kA 5A
Quick-Acting-Fuse Outputs 1 to 8 (F1)
Outputs 9 to 16 (F2)
IOM module
F100-F101-F102
16A V/1,5kA (3,8kVA)
32A V/1,5kA (7kVA)
50A V/1,5kA (16,5kVA)
gG 220 Vac three-phase supply SAU2
F103-F104
250V/1,5kA 20A
35 Vac supply for 24 Vdc robot brake power
module (G100)
F105-F106
250V/1,5kA 6,3A
time-lag-fuse 220 Vac monophase supply for conditioner(op
-
tional)
F108
250V/1,5kA 6,3A
time-lag-fuse Supplies: SAU 2, CU power module (PWR3),
backup module (BKM), SAU2 and BKM fans
(E110-E111)
F109-F110-F111
250V/1,5kA 6,3A
time-lag-fuse 19 Vac three-phase supply for services 24 Vdc
power module (V1)
F113
250V/ 1,5kA 4A
Quick-Acting-Fuse 24 Vdc internal supply to robot, external field
(X30), CU fans, IOM module
F116
250V/ 1,5kA 2A
Quick-Acting-Fuse SIM module 24 Vdc supply
F117
30 mA differential current
6A internal current
differential
magnetothermal switch
220 Vac supply for service socket and internal
lighting
REPLACEMENTS
Specific cautions:
·
Carefully follow the instructions given in GENERAL RULES FOR MAINTENANCE.
C3G Plus MAINTENANCE
01/0498 7-39
PROTECTIONS
