EMERGENCY CONTROL C3G-EMC2 (Only Rel. 2.x)
This is an hand-held device which, when interfacing with the controller unit C3G Plus Rel. 2.x, permits the
implementation of the emergency terminal function by following the same active modes as described under
the paragraphs “Programming and Emergency Terminal” and “Active keys on the emergency terminal” of
this chapter.
C3G-EMC2 CONNECTING PROCEDURE
The steps required to actuate the emergency terminal function are the following:
-
Take X110/SDB3 off (the PTU4 connections are broken);
-
Remove X111/SDB3 (closing plug);
-
Disengage the connector X140/PDP (cut-off of 110 V a.c. supply to the electronics rack);
The non-disconnection of this connector during the emergency terminal function could cause
the system malfunctioning.
-
Connect the cable X110/EMC2 to X110/SDB3 on the card C3G-EMC2;
-
Connect the cable X111/EMC2 running out from the box C3G-EMC2 to the connector X111/SDB3 ;
-
Connect the cable X7/EMC2 running out from the box C3G-EMC2 to the connector X7/SAU2;
- Connect the cable X110/SDB3 running out PTU4 to the connector X110/EMC2.
All the above mentioned operations have to be carried out with great caution
After carrying out the machine handling operation through the emergency terminal, discon
-
nect the hand-held device C3G-EMC2 and reset the original connections.
OPERATOR INTERFACE C3G Plus
3-12 07/1200
EMERGENCY CONTROL (C3G-EMC2)
