If the initialising tests are interrupted and an error code among those listed is displayed, e.g.
“LOCAL DIAGS ON BOARD “RBCO” 00080000, to reset the fault it is necessary to replace
the module that failed the test, in this case, RBC2. The code issued is used by COMAU to
identify the fault and can be mentioned for subsequent module repair.
DIAGNOSTIC LEVEL 3
The PC video emulator and programming terminal display show the controller error messages which differ
according to the fault detected. These error messages are on parallel stored in a file called ERROR.LOG,
resident in the controller memory which may be consulted if the message is erased from the display/PC
video emulator or if requiring to check which alarms have occurred previously. The error messages are in the
following form:
E.G: 28694 - 11 - DRIVE OFF Safety gates or Emergency stop
The meaning of the error message is the following:
28694 (consecutive alarm number); 11 (seriousness level); DRIVE OFF (effect on controller status) Safety
gates or Emergency stop (text of message with fault detected on the system)
Below is a list of the levels of seriousness of the system and their meaning:
Level of se
-
riousness
Meaning Effect of Problem Reset Action
00: Informative message None
01: Informative message None
02: Warning No effect on control
status
03: Not used
04: PDL2 programme error Set the programme to
PAUSE or HOLD if it is
a holdable programme
Reset the programme
pressing the SHIFT and
SCRN keys
05: Not used
06: PDL2 programme error Set all the programmes
to PAUSE or HOLD if
they are holdable
programmes
Reset pressing the SHIFT
and SCRN keys
07: Not used
08: Hold HOLD Reset the programme
pressing the HOLD key
09: Not used
10: Drives off HOLD + DRIVE OFF Reset the programme
pressing the DRIVE OFF
and HOLD keys
11: Drives off DRIVE OFF due to
safety chain open +
HOLD
Reset the programme
pressing the DRIVE OFF
and HOLD keys
12: Drives off HOLD + DRIVE OFF,
DEACTIVATE
(programme deactiva
-
tion)
Reset the programme
pressing the DRIVE OFF
and HOLD keys
C3G Plus MAINTENANCE
00/1097 7-29
