Comau C3G Plus - Commercial Spares

COMAU Spares (Continued)
COMAU CODE DESCRIPTION REFERENCE
10910980
Current loop module SAU2-CLM
10911080
Soft start module SAU2-SSM
10911180
Phase sensor circuit module SAU2-PDM
10911280
DC bus mod. 1 distribution module SAU2-BDDM1
10911380
Auxiliary power supply/digital module SAU2-MDM
10911480
Motor harness mod.1-8axes SAU2-CB8AX
10911580
Motor harness mod.2-6axes SAU2-CB6AX
10911680
Motor harness mod. 2 - 7-8 axes SAU2-CB7-8AX
10913180
Motor harness mod.4-6axes
10911780
DC bus mod. 2 distribution module SAU2-BDDM2
10913080
DC bus mod.3 distribution module SAU2-BDDM2
10911880
Ventilation module SAU2-FM
10911980
Recovery resistance SAU2-RR
10912080
Power rectifier bridge SAU2-PBR
10913280
Power rectifier bridge mod. 2 SAU2-PBR
10912180
Recovery circuit IGBT SAU2-IGTB
Commercial Spares
COMAU CODE DESCRIPTION REFERENCE MANUFACTURER
MANUFACTURER
CODE
00420175
Earth terminal X118-X119 WEIDMULLER WPE10 N.101030
00700134
Fuse-holder terminal with Led (5x20) X119 WEIDMULLER ASK1-LED N.2227.6
00700140
Fuse-holder terminal (5x20) X119 WEIDMULLER ASK1/35 047456
00700878
24 V relay K105, K106 SIEMENS 3RH1131-1JB40
00701018
20 A 10x38 fuse F103, F104 SIEMENS 3NW6007-1
00701014
32 A 14X51 fuse (7 kVA version) F100, F101, F102 SIEMENS 3NW6112-1
00701020
16 A 14X51 fuse (3.8 kVA version) F100, F101, F102 SIEMENS 3NW6005-1
00701024
50 A 14X51 fuse (16.5 kVA version) F100, F101, F102 SIEMENS 3NW6120-1
00701027
25 A 500 V two-pole fuse holder SIEMENS 3NW7021
00701029
50 A 500 V three-pole fuse holder SIEMENS 3NW7131
00701055
5x20 4 A 250 V fuse F113 SCHURTER 0001.1010
00701810
Red mushroom-head button S150 RAFI 1.30043.554/0301
00702542
6-way female connector X114, X160, X161,
X170
AMP 350781-1
00702559
3-way male connector X141, X142 AMP 350766-1
00702561
3-way female connector X140 ÷ X145 AMP 350767-1
00702562
2-way female connector X150, X151, X152 AMP 350778-1
00702566
6-way male connector X161, X166 AMP 350715-1
00702590
250 V 10 A socket (only for Rel. 1.x) X115 PALAZZOLI TAIS 431237
00703158
20-way female connector X117, X107, X108,
X109
MOLEX 5557-20R-210
00703159
24-way female connector X133, X106, X112 MOLEX 5557-24R-210
00703165
18/24 AWG female contact X108, X109, X112,
X133, X106, X107
MOLEX 5556-PBT
00703173
6-way male connector in line X6/SAU2 AMP 640585-1
00703603
6V6Ahbattery RPT BATTERY FIAMM FG 10651
00703645
115 V radial flow fan E110 EBM R2E190-AE79-43-115V
C3G Plus MAINTENANCE
08/0702 7-71
LIST OF SPARE PARTS
