Input/Output MODULES
·
C3G-IOM, 16 Input/16 Output Module
·
C3G-ACI, 32 AC Input Module
·
C3G-DCI, 32 DC Input Module
·
C3G-DLO, 32 DC 0.5 A Output Module
·
C3G-DHO, 32 DC 2A Output Module
·
C3G-ACO, 16 AC 1A Output Module
·
C3G-RLO, 16 AC 2A Relay Output Module
·
C3G-ADM 2 Analogue Output-8DCInput-8DCOutput
The description, layout, meaning of the leds and instructions for connecting the modules are
given in chapter 4 “Guide to integration” of this manual.
REPLACEMENTS
Specific cautions:
· Comply with the “GENERAL RULES FOR MAINTENANCE” given in this chapter.
Special tools: unnecessary
MAINTENANCE C3G Plus
7-48 07/1200
INPUT/OUTPUT MODULES
