Should the system software loading procedure fail (for instance when inserting the wrong

floppy disk), the programming terminal display shows the Bootmon environment. Activate the

characters menu pressing the CHAR key on the PTU4 keyboard and then type the com

mand RESET/INIT. Confirm the command pressing ENTER. The procedure automatically

starts again from the beginning.

After loading the system software, first of all, the current value of the software hour meter,

saved in the flash memory, must be restored, giving one of the following commands: CON

FIGURE ARM RETENTIVE MOMORY LOAD (with options, if required) or CONFIGURE

LOAD. These commands must in any case be executed even to restore the calibration con

stants. Be careful not to enter the BOOTMON environment before giving the above-men

tioned commands not to loose the software hour meter value.

SUBSEQUENT SYSTEM SOFTWARE LOADING WITH SAME VERSION OR LATER

VERSIONS (1/2)

PRELIMINARY OPERATIONS

Using the FD (Filer Delete) command erase the backup files of the user programmes from the C3G

RAM DISK

COMMAND : FD

TYPE : *.bk* or press and select *.bk*

2. Make a backup of the C3G RAM DISK on Personal Computer or on integrated floppy disk by copying all

the files with the FUB (Filer Utility Backup) command.

If the PC is used as backup device, connect to COMP: and activate the video/keyboard emu-

lator of the C3G

Plus through the PCINT programme (see chapter 3).

3. Load the system software again following the procedure described in the previous paragraph.

Load all the files saved previously in the C3G RAM DISK with the FUR command.

Take the robot to the calibration notches either by hand or with the Execute command.

COMMAND: EXECUTE

TYPE: MOVE TO $CAL_SYS

To better understand the software versions, consider:

version X.YZ

where X stands for hardware/software links

Y means Major Release

Z means Minor Release

Examples:

a). from 5.01 to 5.02 Minor Release

b). from 5.01 to 5.10 Major Release

c). from 5.01 to 5.01 Same version

d). from 5.01 to 6.01 Major Release with hardware change.

C3G Plus MAINTENANCE

07/1200 7-61
