Connectors X200 and X201 for robot SMART H4
Connectors X200 and X201 are installed on robot flange distribution unit. If safety flange is
mounted, remove jumpers X9 - X10 on terminal boards X8 and X9 located inside robot arm
sectioning units.
C3G Plus INTEGRATION GUIDE
04/0799 4-19
CONNECTOR X200
PIN SIGNAL
A
+24 Vdc
B
0V (+24Vdc)
C
$DIN [9]
D
$DIN [10]
E
$DIN [11]
F
$DIN [12]
G
$DIN [13]
H
$DOUT [17]
J
$DOUT [18]
K
$DOUT [19]
L
SAFETY FLANGE M1 OUT
M
+24 Vdc
N
NOT CONNECTED
P
$DOUT [27]
R
$DOUT [28]
S
$DOUT [29]
T
SAFETY FLANGE M1 INP
U
$DIN [2]
V
$DIN [3]
W
$DIN [4]
X
$DIN [5]
Y
$DOUT [20]
Z
GROUND
a
SHIELD
b
KSR 1
c
KSR 2
CONNECTOR X201
PIN SIGNAL
A
+24 Vdc
B
0V (+24Vdc)
C
$DIN [6]
D
$DIN [14]
E
AVAILABLE
F
$DOUT [22]
G
$DOUT [23]
H
$DOUT [24]
J
$DOUT [21]
K
$DIN [1]
L
$DOUT [25]
M
$DOUT [26]
N
$DIN [7]
P
$DIN [15]
R
AVAILABLE
S
$DIN [8]
T
HSI -
U
AVAILABLE
V
AVAILABLE
W
AVAILABLE
X
AVAILABLE
Y
AVAILABLE
Z
GROUND
a
AVAILABLE
b
AVAILABLE
c
HSI +
PARALLEL I/O BASIC C3G-IOM
