Comau C3G Plus - List of Spare Parts

LIST OF SPARE PARTS
The spare parts of the C3G Plus control unit are listed in the tables below which are divided as follows:
·
high consumption COMAU spares;
·
COMAU spares;
·
commercial spares.
The COMAU spares table is divided as follows:
·
basic cabinet;
·
electronic modules;
·
extra cables and connectors;
·
accessories;
·
Servo Amplifiers Unit 2.
The information given in the individual columns (if any) is described below:
·
the COMAU Code column gives the component identification code;
·
the Description column gives the name of the assemblies or components;
· the Reference column gives the component reference code;
· the Manufacturer column gives the name of the company that supplies the component;
· the Manufacturer Code column gives the identification code assigned to the components by manufacturer.
High Consumption COMAU Spares
COMAU CODE DESCRIPTION REFERENCE
00701018
20 A 10X38 Fuse F103, F104
00701014
32 A 14X51 Fuse (7 kVA version) F100, F101, F102
00701020
16 A 14X51 Fuse (3.8 kVA version) F100, F101, F102
00701024
50 A 14X51 Fuse (16.5 kVA version) F100, F101, F102
00701055
4 A (5x20) quick acting fuse F113
00703604
4 V Battery CU battery
19270068
2 A 250 V 5X20 quick acting fuse F116
19270076
6.3 A (5X20) time lag fuse F105, F106, F108, F109, F111,
F110
19800111
Male guide pin HARTING connectors
19800112
Female guide pin HARTING connectors
19800113
Sil. plat. male contact 14 AWG HARTING connectors
19800114
Sil. plat. male contact 16 AWG HARTING connectors
19800115
Sil. plat. male contact 26/22 AWG HARTING connectors
19800116
Sil. plat. male contact 20 AWG HARTING connectors
19800118
Sil. plat. female contact 26/22 AWG HARTING connectors
19800119
Sil. plat. female contact 20 AWG HARTING connectors
19800120
Sil. plat. female contact 18 AWG HARTING connectors
19800121
Sil. plat. female contact 16 AWG HARTING connectors
19800126
Sil. plat. female contact 18 AWG HARTING connectors
19920078
Front bezel screw –
19800122
Sil. plat. female contact 14 AWG HARTING connectors
19920154
FIAT wrench –
MAINTENANCE C3G Plus
7-68 08/0702
LIST OF SPARE PARTS
