Comau C3G Plus - Examples of Use of System Signals Dedicated to Transfer Interface; Programme Number Selection from Remote through User-Programmable I;Os

EXAMPLES OF USE OF SYSTEM SIGNALS DEDICATED TO TRANSFER
INTERFACE
EXAMPLE OF PROGRAMME NUMBER SELECTION FROM REMOTE THROUGH
USER-PROGRAMMABLE I/O’s
(1) User-programmable I/O’s (IOM). The signals described are for example purposes and
may be used within a programme for work cycle management.
(2) Control unit initial status: status selector in the Automatic remote position .
(3) If there are no activated programs, START control is not effective and this OUTPUT
remains FALSE.
(5) Another solution for checking the PROGR. CODE consists in sending the C3G a parity
signal which will be checked by the PDL2. In this way, the outputs that provide echo of
the programme code are saved (REC. PROGR. CODE).
C3G Plus INTEGRATION GUIDE
04/0799 4-11
C
3G-CONTROL SYSTEM
X
30/1
X
30/19
X
30/2
DRIVE ON INPUT
DRIVE OFF INPUT
START INPUT
X
30/20
HOLD INPUT
(
1) PROGR. CODE INPUT
(
1) PROGR. STROBE INPUT
(
1)
PROGR. START INPUT
X
30/B DRIVE ON/OFF OUTPUT
X
30/26
START/HOLD OUTPUT
X
30/11 L O CAL/REMO TE OUTPUT
X
30/29
ALARM OUTPUT
X
30/53
DRIVE ON OUTPUT
(POWER CONTACTOR)
(
1)
REC. PROG. CODE INPUT
(5
)
(5
)
(
1)
PROGR. REC. OUTPUT
(ACKNOWLEDGE)
(
1)
END OF PROGRAM /
PROGRAM RUNNING
SYSTEM START UP HW TEST OK
DRIVE ON COMMAND
POWER CONTACTOR
DRIVE ON STATUS
DRIVE ON COMM. REL.
START REL./PROGR. CODE
START COMMAND
DATA STROBE
FEEDBACK PROGR. CODE START PROGR.
PROGRAM RUNNING
END OF PROGR PROGR. CODE
DATA STROBE FEEDBACK PROGR. CODE START PROG.
500 msec MIN.
1500 msec MAX.
50 msec MIN.
200 msec MIN.
500 msec MAX.
500 msec MAX.
50 msec MIN.
50 msec MIN.
(2)
START UP DRIVE ON
PROGR. SELECT.
& START
CHANGE OF PROGRAM
(3)
PROGRAM RUNNING
PROGR. Y
RUNNING
PROG R. X
RUNNING
example of use of system signals
