ELECTROMECHANICAL WARNINGS
Fuse warnings (terminal strip X119):
FUSE LED WARNING
F113 RED - ON Protection of internal 24 Vdc supply to: robot, outside field,
IOM module, Control Unit fans tripped.
F116 RED - ON Protection of 24 Vdc supply for SIM module tripped.
Thermal probe S2 warnings (terminal strip X120):
With versions DDMP - DDHP of the C3G Plus the thermal probe S2 terminals are in terminal
strip X119.
TERMINAL LED WARNING
33 RED - OFF Thermal probe S2 for protection of transformer T100 trip
-
ped.
36 RED - ON Presence of 24 Vdc supply for thermal probe S2
33 36 WARNING
ON ON 24 Vdc supply present
OFF ON Thermal probe S2 tripped
OFF OFF 24 Vdc supply absent
MAINTENANCE C3G Plus
7-40 01/0498
PROTECTIONS
