Comau C3G Plus - Acquaintance with Operator Interface; Check Packing List; Provisions for Installation

To simplify installation operations, the provisions for installation are given in the C3G Plus TECHNICAL
SPECIFICATIONS manual which may be supplied in advance of the product (before installation); in any case
the above-mentioned manual is also supplied herewith.
In the cell controller cabin there is the STANDARD PRODUCT APPROVAL card (scheda di DELIBERA
PRODOTTO STANDARD). Check the presence of the components listed on the card.
Prior to proceeding with installation it is necessary to get acquainted with the cell controller interfaces with
the outside world. Operator interface means all devices suitable for dialogue between the cell controller and
the operator.
· Control panel and serial and parallel interfaces
· Programming and PTU4 emergency terminal
· Display PTU4
· Provisions for activating the emergency terminal
· Emergency terminal active keys
· Connector for additional Enabling Device push-button
·
C3G
Plus interface on PC
-
Connection cable for COMP: - PC connectors
-
Connection cable for serial ports COM0 and COM1 connectors;
-
Connection cable for parallel port PAR:
-
PCINT programme
-
C3G
Plus video on PC
·
System commands
·
Stand-by function
·
Brake Release Device (C3G-BRD)
Detailed explanations of each interface are given in Chapter 3 of this manual.
C3G Plus INSTALLATION
01/4098 2-1
INSTALLATION 1. 2. 3.
1. PROVISIONS FOR INSTALLATION
2. CHECK PACKING LIST
3. ACQUAINTANCE WITH OPERATOR INTERFACE
