Code
Meaning
0002 0000
0004 0000
0008 0000
0010 0000
0020 0000
0040 0000
0080 0000
0100 0000
0200 0000
0400 0000
0800 0000
1000 0000
1800 0000
2000 0000
2800 0000
3000 0000
3800 0000
4000 0000
4800 0000
5000 0000
5800 0000
6000 0000
6800 0000
7000 0000
7800 0000
8000 0000
8800 0000
9000 0000
9800 0000
A000 0000
A800 0000
B000 0000
B800 0000
C000 0000
C800 0000
D000 0000
D800 0000
E000 0000
E800 0000
F000 0000
F800 0001
F800 0002
F801 0002
F802 0102
F802 1002
F803 0002
F804 0102
F806 0102
F810 0102
F836 0102
F836 0802
F836 1002
F836 2002
F838 0102
F838 0202
F838 1002
F838 2002
F800 0004
F800 0008
F800 0010
F800 0020
F800 0040
OS RAM fault
Program RAM fault
IR RAM fault
Enable RAM fault
ROM fault
Simulated scan fault
Watchdog timer fault
Communication port 1 fault
CPU fault
BOARD (requested device) not found
RAM checksum not passed
Parity generator/checker fault
Timer CHIP fault
Watchdog expired unexpectedly
DMA/SCC Port 1 external fault
DMA/SCC Port 2 external fault
Communication port 2 fault
Wrong time
Battery fault
Fault due to high temperature
Timer 2 fault
Bus time out fault
Unexpected interrupt
Unexpected bus error
Diagnostics test being run
Bus interface fault
AC power fail test not passed
RESET register fault
I/O Base fault
Physical address register fault
Logical address register fault
Exception register fault
Output register fault
System fail generator fault
Cooperative test fault
Internal DMA/SCC fault
Unknown test type not passed
Internal DMA/SCC fault
Other error
Error register fault
GCSR error
DSP error
RAM initial error
D/A converter error with channelA<>channel B
D/A converter error with channelA<>1.2V
Timeout error with DSP
Internal DSP timer error
R/D axes mask error
Sine generator error
DSP internal ram error not alone
DSP internal ram error
DSP external ram error
DSP programme ram error
DSP interrupt error, interrupt fails to arrive from outside (or too slow or too fast)
DSP interrupt error, not arrived or incorrect timer interrupt
DSP interrupt error, timer interrupt occurred with interrupt disabled
DSP interrupt error, external interrupt occurred with interrupt disabled
G.A. MISC OUTPUT REG ERROR
ANNEX card fault
Data Bus fault
Fence register inoperative
FP coprocessor fault
MAINTENANCE C3G Plus
7-28 00/1097
diagnostic
