Close
Arm Input Output Program Rll Select Total Vars
Arm Close
Fieldbus Input Output Program Rll Vars
The CLOSE command displays a command menu for removing displayed windows from the screen.
·
Arm closes all ARM windows.
Syntax: DCA
·
Input closes all input windows.
Syntax: DCI
·
Output closes all output windows.
Syntax: DCO
·
Program closes the window concerning active PDL2 programmes.
Syntax: DCP
·
Rll closes the Rll programme window.
Syntax: DCR
· Select closes individual windows selected by the operator.
Syntax: DCS
· Total closes all windows opened by the DISPLAY command.
Syntax: DCT
· Vars closes all variable windows.
Syntax: DCV
Fieldbus
Master Slave
Arm Close Fieldbus
Input Output Rll Vars
The FIELDBUS command contains a menu of commands in order to display the status of the Fieldbus Mas
-
ter and Slave cards.
In particular, the following information can be displayed for each card:
NOCNFG indicates that the card is not configured;
RUNNING indicates that the communication is active;
STOPPED indicates that the communication is not active.
If no Fieldbus card is present no display is open.
·
Master displays the information on the IBS-MASTER card.
Syntax: DFM
·
Slave displays the information on the IBS-SLAVE, PROFIBUS-DP, DEVICE NET and RIO cards.
Syntax: DFS
C3G Plus OPERATOR INTERFACE
07/1200 3-29
DISPLAY COMMAND
