CRITICALPOINT 700/800MHZ BDA/DAS/BBU V3 USER MANUAL
©2024 Comba Telecom. All Rights Reserved.
568 Gibraltar Drive, Milpitas, CA 95035 | +1 408 526 0180
Rev. 1-0-2 Rev. Date: 11-1-2024
Page: 167
Figure 143: Commissioning Fiber DAS – Batch Setting RU Output ATT and UL Gain Limit
Set the DL Output
ATT per Band
Set the UL
Gain Limit
Select the RUs to
configure Output ATT
and UL Gain Limit
Click Batch Setting
to apply to RUs
