Table 39: IFC 510 2021 Alarm Preset Dry Contact and LED Operation
LED/Dry
Contact
IFC 510 2021
Default Alarm Configuration
1
LOSS OF NORMAL AC POWER
SUPPLY
AC Lost Alarm
System Dry ALM 1
2
SYSTEM BATTERY CHARGER(S)
FAILURE
Charger Fault Alarm
Charger Comm. Fault Alarm
System Dry ALM 2
3
MALFUNCTION OF THE DONOR
ANTENNA(S)
DT ANT Disconnection Alarm
System Dry ALM 3
4
FAILURE OF ACTIVE RF-EMITTING
DEVICE(S)
PA Alarm 700/800 DL/UL
DL P_in Over Alarm 700/800 DL
DL P_out Over Alarm 700/800 DL
LNA Alarm 700/800 DL/UL
Oscillation Shutdown Alarm
Oscillation Gain Reduction Alarm
PLL Alarm
Digital Clock Alarm
VSWR Alarm DL 700/800
Over Temperature Alarm
System OP TX Alarm
System OP RX Alarm
FOU Comm. Fault Alarm (FOU1~4)
System Dry ALM 4
5
LOW-BATTERY CAPACITY AT 70%
REDUCTION OF OPERATING
CAPACITY
Battery Low Alarm
Battery Connection Fail Alarm
Battery Over Temperature Alarm
Battery Comm. Fault Alarm
Battery Over Discharge Alarm
System Dry ALM 5
6
FAILURE OF CRITICAL SYSTEM
COMPONENTS
Same as “FAILURE OF ACTIVE RF-EMITTING
DEVICE(S)System Dry ALM 6
7
ERRCS ANNUNCIATOR PANEL
COMMUNICATION ALARM
AP Comm. Fault Alarm (AP1~4)
System Dry ALM 7
8
OSCILLATION OF ACTIVE RF-
EMITTING DEVICE
Oscillation Shutdown Alarm
Oscillation Gain Reduction Alarm
System Dry ALM 8
