Table 38: NFPA 1225 2022 Alarm Preset Dry Contact and LED Operation
LED/Dry
Contact
NFPA 1225 2022
Default Alarm Configuration
1
NORMAL AC POWER
AC Normal
System Dry ALM 1
2
LOSS OF NORMAL AC POWER
AC Lost Alarm
System Dry ALM 2
3
BATTERY-CHARGER FAILURE
Charger Fault Alarm
Charger Comm. Fault Alarm
System Dry ALM 3
4
LOW-BATTERY CAPACITY
Battery Low Alarm
Battery Connection Fail Alarm
Battery Over Temperature Alarm
Battery Comm. Fault Alarm
Battery Over Discharge Alarm
System Dry ALM 4
5
SIGNAL SOURCE MALFUNCTION
DT ANT Disconnection Alarm
System Dry ALM 5
6
ACTIVE RF-EMITTING DEVICE
MALFUNCTION
PA Alarm 700/800 DL/UL
DL P_in Over Alarm 700/800 DL
DL P_out Over Alarm 700/800 DL
LNA Alarm 700/800 DL/UL
Oscillation Shutdown Alarm
Oscillation Gain Reduction Alarm
PLL Alarm
Digital Clock Alarm
VSWR Alarm DL 700/800
Over Temperature Alarm
System OP TX Alarm
System OP RX Alarm
FOU Comm. Fault Alarm (FOU1~4)
System Dry ALM 6
7
ACTIVE SYSTEM COMPONENT
MALFUNCTION
Same as “ACTIVE RF-EMITTING DEVICE
MALFUNCTION”
System Dry ALM 7
8
Blank
Blank
