Table 37: UL2524 Oct 2018 Alarm Preset Dry Contact and LED Operation
LED/Dry
Contact
UL2524 OCT 2018
Default Alarm Configuration
1
AC Input Normal
AC Normal
System Dry ALM 1
2
Loss of normal AC power
AC Lost Alarm
System Dry ALM 2
3
Loss of battery capacity
Battery Low Alarm
Battery Connection Fail Alarm
Battery Over Temperature Alarm
Battery Comm. Fault Alarm
Battery Over Discharge Alarm
System Dry ALM 3
4
Battery charger failure
Charger Fault Alarm
Charger Comm. Fault Alarm
System Dry ALM 4
5
Active RF-emitting device
malfunction
PA Alarm 700/800 DL/UL
DL P_in Over Alarm 700/800 DL
DL P_out Over Alarm 700/800 DL
LNA Alarm 700/800 DL/UL
Oscillation Shutdown Alarm
Oscillation Gain Reduction Alarm
PLL Alarm
Digital Clock Alarm
VSWR Alarm DL 700/800
Over Temperature Alarm
System OP TX Alarm
System OP RX Alarm
FOU Comm. Fault Alarm (FOU1~4)
System Dry ALM 5
6
Donor antenna malfunction
DT ANT Disconnection Alarm
System Dry ALM 6
7
System component malfunction
Same as “Active RF-emitting device malfunction”
System Dry ALM 7
8
Donor antenna disconnection
DT ANT Disconnection Alarm
System Dry ALM 8
