Copeland E3 - Page 165

©2025 Copeland LP.
026-1803 R13 Supervisor I&O User Guide A - 2
Read Data
Failed AI 06
Device
Alarm
IPX6/IPX15/IPX25
Can be configured to different sensor types; they can be
configured as “
Input not used” or “Digital Input”. If configured to
a specific type sensor, whereas there is no sensor connected to
this port or there is something wrong with the connected
sensor, and no valid data can be read from the analog input, the
corresponding alarm will be generated. The alarm is not
applicable if the analog input is configured to “
Input not used”
or “
Digital Input”.
Read Data
Failed AI 07
Device
Alarm
IPX6/IPX15/IPX25
Can be configured to different sensor types; they can be
configured as “
Input not used” or “Digital Input”. If configured to
a specific type sensor, whereas there is no sensor connected to
this port or there is something wrong with the connected
sensor, and no valid data can be read from the analog input, the
corresponding alarm will be generated. The alarm is not
applicable if the analog input is configured to “
Input not used”
or “
Digital Input”.
Read Data
Failed AI 08
Device
Alarm
IPX15/IPX25
Can be configured to different sensor types; they can be
configured as “
Input not used” or “Digital Input”. If configured to
a specific type sensor, whereas there is no sensor connected to
this port or there is something wrong with the connected
sensor, and no valid data can be read from the analog input, the
corresponding alarm will be generated. The alarm is not
applicable if the analog input is configured to “
Input not used”
or “
Digital Input”.
Read Data
Failed AI 09
Device
Alarm
IPX15/IPX25
Can be configured to different sensor types; they can be
configured as “
Input not used” or “Digital Input”. If configured to
a specific type sensor, whereas there is no sensor connected to
this port or there is something wrong with the connected
sensor, and no valid data can be read from the analog input, the
corresponding alarm will be generated. The alarm is not
applicable if the analog input is configured to “
Input not used”
or “
Digital Input”.
Read Data
Failed AI 10
Device
Alarm
IPX15/IPX25
Can be configured to different sensor types; they can be
configured as “
Input not used” or “Digital Input”. If configured to
a specific type sensor, whereas there is no sensor connected to
this port or there is something wrong with the connected
sensor, and no valid data can be read from the analog input, the
corresponding alarm will be generated. The alarm is not
applicable if the analog input is configured to “
Input not used”
or “Digital Input”.
Read Data
Failed AI 01
System
Alarm
OnBoard
Should be generated if sensors are configured but
disconnected. If the advisory is reset, and the alarm/notice
condition still exists, the delay period will be used. Advisories
will return to normal if the command value stays in the non-
alarm/notice condition.
Alarm Items Category Cell Name Description
