026-1803 R13 Supervisor I&O User Guide B - 8
Steps for Updating the ETH1 IP Address and Resuming Communication
STEP 1: Once the confirmation window appears, click OK to proceed or Cancel to stop.
STEP 2: Using a USB thumb drive, create a file in the root directory called network.txt and enter the following:
[Control]
eth0IP=<address of ETH1 on the E3>
eth0Mask=255.255.255.0
eth0Port=32000
If the IP address schema is drastically changing or if placing multiple E3s on the same private ETH1 network, then include the
following to configure the PIB network settings.
Note: Peer communications are only available over ETH0.
Only include this section in the file if changing PIB IP device configuration:
[Display]
eth0IP=<address to configure PIB>
eth0Mask=255.255.255.x
eth0GW=<default gateway>
Instructions for network.txt file contents:
If Using a Thumb Drive Definition
[Control] Section separator - must be included as is
eth0IP=<address of ETH1 on the E3> Change this to match the E3 ETH1 address’ new configuration
eth0Mask=255.255.255.0 Should only be changed to match IP schema
eth0Port=32000 DO NOT CHANGE THIS - but it must be included in file
If Changing the PIB IP Device Configuration Definition
[Display] Section separator - must be included as is
eth0IP=<address to configure PIB> Change this to match the E3 ETH1 address’ new configuration
eth0Mask=255.255.255.x Should only be changed to match IP schema
eth0GW=<default gateway> Should only be changed to match IP schema
