Chapter 4 Parameters
4-82
These settings are used when multi-function input terminals are set to 19/20.
02-09 Digital Input Response Time Unit: 0.001
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory setting: 0.005
Settings 0.001~ 30.000 sec
This parameter is used for digital input terminal signal delay and confirmation. The
delay time is confirmation time to prevent some uncertain interferences that would
result in error (except for the counter input) in the input of the digital terminals (FWD,
REV and MI1~6). Under this condition, confirmation for this parameter could be
improved effectively, but the response time will be somewhat delayed.
02-10 Digital Input Operation Direction Unit: 1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory setting: 0
Settings 0 ~ 65535
The setting of this parameter is decimal value.
This parameter is used to set the input signal level and it won’t be affected by the
SINK/SOURCE status.
Bit0 is for FWD terminal, bit1 is for REV terminal and bit2 to bit15 is for MI1 to MI14.
User can change terminal status by communicating.
For example, MI1 is set to 1 (multi-step speed command 1), MI2 is set to 2 (multi-step
speed command 2). Then the forward + 2
nd
step speed command=1001(binary)=9
(Decimal). Only need to set Pr.02-10=9 by communication and it can forward with 2
nd
step speed. It doesn’t need to wire any multi-function terminal.
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
MI14 MI13 MI12 MI11 MI10 MI9 MI8 MI7 MI6 MI5 MI4 MI3 MI2 MI1 REV FWD
02-11 Multi-function Output 1 RA, RB, RC (Relay1)
Factory Setting: 11
02-12
Multi-function Output 2 MRA, MRC (Relay2)
Factory Setting: 1
02-13
Multi-function Output 3 (MO1)
Factory Setting: 0
