Chapter 4 Parameters
4-167
Content Address Function
Bit 13~14 00B: No function
01B: operated by digital keypad
02B: operated by Pr.00-21 setting
03B: change operation source
Bit 15 Reserved
2001H Frequency command
2002H
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Bit 2 1: B.B. ON
Bit 3-15 Reserved
Status
monitor
Read only
2100H Error code: refer to Pr.06-17 to Pr.06-22
2119H
Bit 0 1: FWD command
Bit 1 1: Operation status
Bit 2 1: Jog command
Bit 3 1: REV command
Bit 4 1: REV command
Bit 8
1: Master frequency Controlled by communication
interface
Bit 9 1: Master frequency controlled by analog signal
Bit 10
1: Operation command controlled by
communication interface
Bit 11 1: Parameters have been locked
Bit 12 1: enable to copy parameter from keypad
Bit 13-15 Reserved
2102H Frequency command (F)
2103H Output frequency (H)
2104H Output current (AXXX.X)
2105H DC-BUS Voltage (UXXX.X)
2106H Output voltage (EXXX.X)
2107H Current step number of Multi-Step Speed Operation
2109H Counter value
2116H Multi-function display (Pr.00-04)
211AH Setting frequency (F)
211BH Max. setting frequency
211CH Max. output frequency
2200H Feedback Signal (XXX.XX %)
2203H AVI analog input (XXX.XX %)
2204H ACI analog input (XXX.XX %)
2205H AUI analog input (XXX.XX %)
2206H Display temperature of IGBT (
o
C)
2207H Display temperature of heatsink (
o
C)
2208H Digital input status
2209H Digital output status
3.6 Exception response:
The AC motor drive is expected to return a normal response after receiving command
messages from the master device. The following depicts the conditions when no normal
response is replied to the master device.
The AC motor drive does not receive the messages due to a communication error; thus,
the AC motor drive has no response. The master device will eventually process a timeout
condition.
