Delta VFD-VE - Version 2.05 - Group 7 Special Parameters

Chapter 4 Parameters
4-43
Pr. Explanation Settings
F
actory
Setting
VF VFPG SVC FOCPG TQCPG
45: PG slip error (PGF4)
○ ○
46: PG ref input error (PGr1)
○ ○ ○ ○ ○
47: PG ref loss (PGr2)
○ ○ ○ ○ ○
48: Analog current input loss (ACE)
○ ○ ○ ○ ○
49: External fault input (EF)
○ ○ ○ ○ ○
50: Emergency stop (EF1)
○ ○ ○ ○ ○
51: External Base Block (B.B.)
○ ○ ○ ○ ○
52: Password error (PcodE)
○ ○ ○ ○ ○
53: Reserved
54: Communication error (cE1)
○ ○ ○ ○ ○
55: Communication error (cE2)
○ ○ ○ ○ ○
56: Communication error (cE3)
○ ○ ○ ○ ○
57: Communication error (cE4)
○ ○ ○ ○ ○
58: Communication Time-out (cE10)
○ ○ ○ ○ ○
59: PU time-out (cP10)
○ ○ ○ ○ ○
60: Brake transistor error (bF)
○ ○ ○ ○ ○
61: Y-connection/-connection switch error (ydc)
○ ○ ○ ○
62: Decel. Energy Backup Error (dEb)
○ ○ ○ ○ ○
63: Slip error (oSL)
○ ○ ○ ○
64: Broken belt error (bEb)
○ ○ ○ ○ ○
65: Error PID feedback signal of tension (tdEv)
○ ○ ○ ○ ○
06-32
Output Frequency for
Malfunction
0.00~655.35 Hz
Read-
only
○ ○ ○ ○ ○
06-33
Output Voltage fo
r
Malfunction
0.0~6553.5 V
Read-
only
○ ○ ○ ○ ○
06-34
DC Voltage fo
r
Malfunction
0.0~6553.5 V
Read-
only
○ ○ ○ ○ ○
06-35
Output Current fo
r
Malfunction
0.00~655.35 Amp
Read-
only
○ ○ ○ ○ ○
06-36
IGBT Temperature for
Malfunction
0.0~6553.5 °C
Read-
only
○ ○ ○ ○ ○
Group 7 Special Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
07-05
Proportional Gain for
DC Brake
1~500 50
○ ○ ○
07-19
Fan Control 0: Fan always ON
1: 1 minute after AC motor drive stops, fan will be OFF
2: AC motor drive runs and fan ON, AC motor drive
stops and fan OFF
3: Fan ON to run when preliminary heat sink
temperature(around 60
o
C) attained
4: Fan always OFF
0
○ ○ ○ ○ ○
07-27
Source of Torque
Offset
0: Disable
1: Analog input (Pr.03-00)
2: Torque offset setting
3: Control by external terminal (by Pr.07-29 to Pr.07-
31)
0
○ ○ ○
07-36
Emergency Stop (EF)
& Forced Stop
Selection
0: Coast stop
1: By deceleration Time 1
2: By deceleration Time 2
3: By deceleration Time 3
4: By deceleration Time 4
5: System Deceleration
6: Automatic Deceleration
0
○ ○ ○ ○ ○
