Chapter 4 Parameters
4-108
05-24
Torque Compensation Gain
Unit: 1
Control
mode
VF VFPG
Factory setting: 0
Settings 0 to10
This parameter may be set so that the AC motor drive will increase its voltage output to
obtain a higher torque. Only to be used for SVC control mode.
Too high torque compensation can overheat the motor.
05-25 Slip Compensation Gain Unit: 0.01
Control
mode
VF SVC
Factory setting: 0.00
Settings 0.00 to10.00
When the asynchronous motor is driven by the drive, the load and slip will be increased.
This parameter can be used to correct frequency compensation and lower the slip to
make the motor can run near the synchronous speed under rated current. When the
output current is larger than the motor no-load current, the drive will compensate the
frequency by Pr.05-25 setting. If the actual speed is slower than expectation, please
increase the setting and vice versa.
It is only valid in SVC/VF mode.
The factory settings are:
A. In SVC mode, the factory setting is 1.00.
B. In VF mode, the factory setting is 0.00.
05-26
Slip Deviation Level
Unit: 1
Control
mode
VFPG SVC FOCPG
Factory setting: 0
Settings 0 to 1000% (0: disable)
05-27 Detection time of Slip Deviation Unit: 0.1
Control
mode
VFPG SVC FOCPG
Factory setting: 1.0
Settings 0.0 to 10.0 sec
