Chapter 4 Parameters
4-151
08-46 Initial Reel Diameter Unit: 0.1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 1.0
Settings 0.0 to 6000.0mm
When Pr.08-45 is set to 1, Pr.08-46 will be read-only.
08-47 Initial Reel Diameter 1 Unit: 0.1
08-48 Initial Reel Diameter 2 Unit: 0.1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 1.0
Settings 0.0 to 6000.0mm
Pr.08-46 needs to be used by setting 44~46 to Pr.02-01~02-06, Pr.02-23~Pr.02-30.
When you need to have many types of reel diameter, please set Pr.08-45 to 0 (set by
communication). For example: Pr.08-46 setting can be changed by inputting the digital
keypad, HMI page plan or text panel(PLC product: TP series) via communication.
When the drive is at stop and it is in tension control mode, it needs to set 3-step initial
reel diameter (Pr.08-46~48) by the digital status of multi-function input terminal setting
45 and 46 before using terminal 44 as shown in the following table.
MI=46 MI=45 MI=44
OFF OFF ON: it will write Pr.08-46 into Pr.54
OFF ON ON: it will write Pr.08-47 into Pr.08-54
ON OFF ON: it will write Pr.08-48 into Pr.08-54
ON ON ON:it will reset Pr.08-54 to the factory setting
08-49 Number of Pulse Per Revolution Unit: 1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 1
Settings 1 to 10000ppr
When Pr.08-42 is set to 1, it needs to be used with this parameter. This parameter is the
number of pulse per revolution that a reel rotates.
08-50 Coil Number for Each Layer Unit: 1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 1
Settings 1 to 10000
It is used to set the coil number that a reel needs to increase a layer.
