Delta VFD-VE - Group 1 Basic Parameters

Chapter 4 Parameters
4-4
Group 1 Basic Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
01-00 Maximum Output Frequency
50.00~600.00Hz 60.00/
50.00
○ ○ ○ ○ ○
01-01
1st Output Frequency Setting
1
0.00~600.00Hz 60.00/
50.00
○ ○ ○ ○ ○
01-02 1st Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
220.0
440.0
○ ○ ○ ○ ○
01-03
2nd Output Frequency
Setting 1
0.00~600.00Hz 0.50
○ ○
01-04
2nd Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
5.0
10.0
○ ○
01-05
3rd Output Frequency Setting
1
0.00~600.00Hz 0.50
○ ○
01-06
3rd Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
5.0
10.0
○ ○
01-07
4th Output Frequency Setting
1
0.00~600.00Hz 0.00
○ ○ ○ ○
01-08
4th Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V
0.0
0.0
○ ○
01-09 Start Frequency
0.00~600.00Hz 0.50
○ ○ ○ ○
01-10
Output Frequency Upper Limit 0.00~600.00Hz
600.00
○ ○ ○ ○
01-11
Output Frequency Lower Limit 0.00~600.00Hz
0.00
○ ○ ○ ○
01-12
Accel Time 1 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-13
Decel Time 1 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-14
Accel Time 2 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-15
Decel Time 2 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-16
Accel Time 3 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-17
Decel Time 3 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-18
Accel Time 4 0.00~600.00 sec/0.00~6000.0 sec
10.00/
10.0
○ ○ ○ ○
01-19
Decel Time 4
0.00~600.00 sec/0.00~6000.0 sec 10.00/
10.0
○ ○ ○ ○
01-20
JOG Acceleration Time 0.00~600.00 sec/0.00~6000.0 sec
1.00/
1.0
○ ○ ○ ○
01-21
JOG Deceleration Time 0.00~600.00 sec/0.00~6000.0 sec
1.00/
1.0
○ ○ ○ ○
01-22
JOG Frequency
0.00~600.00Hz 6.00
○ ○ ○ ○ ○
01-23
1st/4th Accel/decel Frequency
0.00~600.00Hz 0.00
○ ○ ○ ○
01-24
S-curve for Acceleration
Departure Time 1
0.00~25.00 sec/0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-25
S-curve for Acceleration
Arrival Time 2
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-26
S-curve for Deceleration
Departure Time 1
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-27
S-curve for Deceleration
Arrival Time 2
0.00~25.00 sec /0.00~250.0 sec 0.2/0.0
○ ○ ○ ○
01-28 Skip Frequency 1 (upper limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-29 Skip Frequency 1 (lower limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-30 Skip Frequency 2 (upper limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-31 Skip Frequency 2 (lower limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-32 Skip Frequency 3 (upper limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-33 Skip Frequency 3 (lower limit)
0.00~600.00Hz 0.00
○ ○ ○ ○
01-34
Mode Selection when
Frequency < Fmin
0: Output Waiting
1: Zero-speed operation
2: Fmin (4th output frequency setting)
0
○ ○ ○ ○
01-35
1st Output Frequency Setting
2
0.00~600.00Hz 60.00/
50.00
○ ○ ○ ○ ○
01-36 1st Output Voltage Setting 2
230V: 0.1V~255.0V
460V: 0.1V~510.0V
220.0
440.0
○ ○ ○ ○ ○
01-37
2nd Output Frequency Setting
2
0.00~600.00Hz 0.50
○ ○
01-38
2nd Output Voltage Setting 2
230V: 0.1V~255.0V 5.0/
○ ○
