Delta VFD-VE - Version 2.05 - Group 10 Speed Feedback Control Parameters

Chapter 4 Parameters
4-45
Group 10 Speed Feedback Control Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
10-02
Encode
r
Feedback
Fault Treatment
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
2
○ ○ ○
10-03
Detection Time for
Encoder Feedback
Fault
0.00~10.0 sec 1.0
○ ○ ○
10-04
ASR (Auto Speed
Regulation) Control
( P) 1
0~40 10
○ ○ ○
10-05
ASR (Auto Speed
Regulation) Control (I)
1
0.000~10.000 sec 0.100
○ ○ ○
10-06
ASR (Auto Speed
Regulation) Control
( P) 2
0~40 10
○ ○ ○
10-07
ASR (Auto Speed
Regulation) Control (I)
2
0.000~10.000 sec 0.100
○ ○ ○
10-08
ASR 1/ASR2 Switch
Frequency
5.00~600.00Hz 7.00
○ ○ ○
10-09
Low Pass Filter Time
of ASR Output
0.000~0.350 sec 0.008
○ ○
10-10
Encode
r
Stall Level
0~120% (0: disable) 115
○ ○
10-11
Encode
r
Stall
Detection Time
0.0~2.0 sec 0.1
○ ○
10-12
Encode
r
Slip Range
0~50% (0: disable) 50
○ ○
10-13
Encode
r
Slip
Detection Time
0.0~10.0 sec 0.5
○ ○
10-14
Encode
r
Stall and Slip
Error Treatment
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
2
○ ○
10-17
Electrical Gea
r
A
(PG1 of PG card)
1~5000 100
○ ○
10-18
Electrical Gea
r
B
(PG2 of PG card)
1~5000 100
○ ○
10-19
Positioning for
Encoder Position
0~65535 pulses
0
○ ○
10-20
Range for Encode
r
Position Attained
0~20000 pulses 10
○ ○
10-21
P Gain of Zero Speed
0~40 10
○ ○ ○
10-22
I Gain of Zero Speed
0.000~10.000 sec 0.100
○ ○ ○
10-23
Feed Forward Gain
of APR
0~100 30
○ ○
10-24
Deceleration Time for
Internal
Position/Waiting Time
for Switching Max.
Frequency
0.00~600.00 sec/00~6000.0 sec 3.00
3.0
○ ○
10-27
Mechanical Gear at
Load A1
1~65535 100
○ ○ ○
10-28
Mechanical Gear at
Motor B1
1~65535 100
○ ○ ○
10-29
Mechanical Gear at
Load A2
1~65535 100
○ ○ ○
10-30
Mechanical Gear at
Motor B2
1~65535 100
○ ○ ○
