Delta VFD-VE - 06 H: Single Write, Write Single Data to Register

Chapter 4 Parameters
4-163
Command message:
Response message:
Number of data
(count by word)
‘0’ 2102H ‘7’
‘0’ ‘0’
‘0’
Content of address
2103H
‘0’
‘2’ ‘0’
LRC Check
‘D’ ‘0’
‘7’ ‘0’
END
CR
LRC Check
‘7’
LF ‘1’
END
CR
LF
RTU mode:
Command message:
Response message:
Address 01H
Address 01H
Function 03H
Function 03H
Starting data
address
21H
Number of data
(count by byte)
04H
02H
Number of data
(count by word)
00H
Content of address
2102H
17H
02H 70H
CRC CHK Low 6FH
Content of address
2103H
00H
CRC CHK High F7H 00H
CRC CHK Low FEH
CRC CHK High 5CH
(2) 06H: single write, write single data to register.
Example: writing data 6000(1770H) to register 0100H. AMD address is 01H.
ASCII mode:
Command message: Response message:
STX ‘:’ STX ‘:’
Address
‘0’
Address
‘0’
‘1’ ‘1’
Function
‘0’
Function
‘0’
‘6’ ‘6’
Data address
‘0’
Data address
‘0’
‘1’ ‘1’
‘0’ ‘0’
‘0’ ‘0’
Data content
‘1’
Data content
‘1’
‘7’ ‘7’
‘7’ ‘7’
‘0’ ‘0’
LRC Check
‘7’
LRC Check
‘7’
‘1’ ‘1’
END
CR
END
CR
LF LF
RTU mode:
Command message:
Response message:
Address 01H Address 01H
Function 06H Function 06H
Data address
01H
Data address
01H
00H 00H
