Delta VFD-VE - Version 2.05 - Group 6 Protection Parameters

Chapter 4 Parameters
4-42
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
05-21
Stator Inductance(Lx)
of Motor 2
0~6553.5mH #.#
○ ○ ○
Group 6 Protection Parameters
Pr. Explanation Settings
F
actory
Setting
VF VFPG SVC FOCPG TQCPG
06-03
Over-current Stall
Prevention during
Acceleration
00~250% (100%: drive’s rated current)
170
○ ○ ○
06-04
Over-current Stall
Prevention during
Operation
00~250% (100%: drive’s rated current)
170
○ ○ ○
06-07
Over-torque Detection
Level (OT1)
10~250%(100%: drive’s rated current)
150
○ ○ ○ ○ ○
06-10
Over-torque Detection
Level (OT2)
10~250%(100%: drive’s rated current)
150
○ ○ ○ ○ ○
06-12
Current Limit
0~250%(100%: drive’s rated current)
150
○ ○
06-17 Present Fault Record 0: No fault 0
○ ○ ○ ○ ○
1: Over-current during acceleration (ocA)
○ ○ ○ ○ ○
06-18
Second Most Recent
Fault Record
2: Over-current during deceleration (ocd) 0
○ ○ ○ ○ ○
3: Over-current during constant speed (ocn)
○ ○ ○ ○ ○
4: Ground fault (GFF)
○ ○ ○ ○ ○
06-19
Third Most Recent
Fault Record
5: IGBT short-circuit (occ) 0
○ ○ ○ ○ ○
6: Over-curent at stop (ocS)
○ ○ ○ ○ ○
7: Over-voltage during acceleration (ovA)
○ ○ ○ ○ ○
06-20 Fourth Most Recent
Fault Record
8: Over-voltage during deceleration (ovd) 0
○ ○ ○ ○ ○
9: Over-voltage during constant speed (ovn)
○ ○ ○ ○ ○
10: Over-voltage at stop (ovS)
○ ○ ○ ○ ○
11: Low-voltage during acceleration (LvA)
○ ○ ○ ○ ○
06-21 Fifth Most Recent
Fault Record
12: Low-voltage during deceleration (Lvd)
○ ○ ○ ○ ○
13: Low-voltage during constant speed (Lvn)
○ ○ ○ ○ ○
14: Low-voltage at stop (LvS) 0
○ ○ ○ ○ ○
15: Phase loss (PHL)
○ ○ ○ ○ ○
16: IGBT ove
r
-heat (oH1)
○ ○ ○ ○ ○
06-22 Sixth Most Recent
Fault Record
17: Heat sink over-heat (oH2)(for 40HP above) 0
○ ○ ○ ○ ○
18: TH1: IGBT hardware failure (tH1o)
○ ○ ○ ○ ○
19: TH2: Heat sink hardware failure(tH2o)
○ ○ ○ ○ ○
20: Fan error signal output
○ ○ ○ ○ ○
21: ove
r
-load (oL) (when it exceeds 150% rated
current, 1 min later it will be overload)
○ ○ ○ ○ ○
22: Electronics thermal relay 1 (EoL1)
○ ○ ○ ○ ○
23: Electronics thermal relay 2 (EoL2)
○ ○ ○ ○ ○
24: Motor PTC overheat (oH3)
○ ○ ○ ○ ○
25: Fuse error (FuSE)
○ ○ ○ ○ ○
26: over-torque 1 (ot1)
○ ○ ○ ○ ○
27: over-torque 1 (ot2)
○ ○ ○ ○ ○
28: Reserved
29: Reserved
30: Memory write-in error (cF1)
○ ○ ○ ○ ○
31: Memory read-out error (cF2)
○ ○ ○ ○ ○
32: Isum current detection error (cd0)
○ ○ ○ ○ ○
33: U-phase current detection error (cd1)
○ ○ ○ ○ ○
34: V-phase current detection error (cd2)
○ ○ ○ ○ ○
35: W-phase current detection error (cd3)
○ ○ ○ ○ ○
36: Clamp current detection error (Hd0)
○ ○ ○ ○ ○
37: Over-current detection error (Hd1)
○ ○ ○ ○ ○
38: Over-voltage detection error (Hd2)
○ ○ ○ ○ ○
39: Ground current detection error (Hd3)
○ ○ ○ ○ ○
40: Auto tuning error (AuE)
○ ○ ○
41: PID feedback loss (AFE)
○ ○ ○ ○ ○
42: PG feedback error (PGF1)
○ ○ ○
43: PG feedback loss (PGF2)
○ ○ ○
44: PG feedback stall (PGF3)
○ ○
