Delta VFD-VE - 4.1 Summary of Parameter Settings

Chapter 4 Parameters
4-2
4.1 Summary of Parameter Settings
: The parameter can be set during operation.
Group 0 System Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
00-00
Identity Code of the AC
motor drive
Read-only 0
○ ○ ○ ○ ○
00-01
Rated Current Display of
the AC motor drive
Read-only 0
○ ○ ○ ○ ○
00-02
Parameter Reset
0: No function
1: Read only
2: Enable group 11 parameters setting
8: Keypad lock
9: All parameters are reset to factory settings (50Hz,
220V/380V)
10: All parameters are reset to factory settings (60Hz,
220V/440V)
0
○ ○ ○ ○ ○
00-03
Start-up Display Selection
0: Display the frequency command value (LED F)
1: Display the actual output frequency (LED H)
2: Multifunction display, see Pr.00-04 (LED U)
3: Display the output current (A)
0
○ ○ ○ ○ ○
00-04
Content of Multi Function
Display
0: Display output current (A)
1: Display counter value (C)
2: Display output frequency (H)
3: Display DC-BUS voltage (
u
)
4: Display output voltage (E)
5: Output power factor angle (n)
6: Display output power (kW)
7: Display actual motor speed (r)
8: Display estimate output torque in N-m (t)
9: Display PG position (G)
10: Display PID feedback in % (b)
11: Display AVI in % (1.)
12: Display ACI in % (2.)
13: Display AUI in % (3.)
14: Display the temperature of heat sink in °C (t.)
15: Display the temperature of IGBT in °C (T)
16: The status of digital input (ON/OFF) (i)
17: The status of digital output (ON/OFF) (o)
18: Multi-step speed (S)
19: The corresponding CPU pin status of digital input (i.)
20: The corresponding CPU pin status of digital output
(o.)
21: Number of actual motor revolution (PG1 of PG card)
(Z)
22: Pulse input frequency (PG2 of PG card) (4)
23: Pulse input position (PG2 of PG card) (4.)
24: Pulse position control for whole operation (MI=37
and MI=ON) (P.)
25: Display the present reel diameter under the tension
control in mm (d)
26: Display the present line speed under the tension
control in m/min (L)
27: Display the present tension setting under the tension
control in N (T.)
0
○ ○ ○ ○ ○
00-05
User-Defined Coefficient K
Digit 4: decimal point number (0 to 3)
Digit 0-3: 40 to 9999
0
○ ○ ○ ○ ○
00-06 Software Version Read-only
#.#
○ ○ ○ ○ ○
00-07
Password Input
1 to 9998 and 10000 to 65535
0 to 2: times of wrong password
0
○ ○ ○ ○ ○
00-08
Password Set
1 to 9998 and 10000 to 65535
0: No password set or successful input in Pr.00-07
1: Password has been set
0
○ ○ ○ ○ ○
00-09
Energy Saving Gain
10~1000 % 100%
○
00-10
Control Method
0: V/f Control
1: V/f Control + Encoder (VFPG)
2: Sensorless vector control (SVC)
3: FOC vector control + Encoder (FOCPG)
4: Torque control + Encoder (TQCPG)
0
○ ○ ○ ○ ○
