Chapter 4 Parameters
4-44
Group 8 High-function PID Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
08-00
Input Terminal for PID
Feedback
0: No function
1: Negative PID feedback from external terminal AVI
(Pr.03-00)
2: Negative PID feedback from PG card (Pr.10-15, skip
direction)
3: Negative PID feedback from PG card (Pr.10-15)
4: Positive PID feedback from external terminal AVI
(Pr.03-00)
5: Positive PID feedback from PG card (Pr.10-15, skip
direction)
6: Positive PID feedback from PG card (Pr.10-15)
0
○ ○ ○ ○
08-21
Tension Control
Selection
0: Disable 0
○ ○ ○ ○
1: Tension closed-loop, speed mode
○ ○ ○ ○
2: Line speed closed-loop, speed mode
○ ○ ○ ○
3: Reserved
4: Tension open-loop, torque mode
○
08-22
Wind Mode 0: Rewind
1: Unwind
0
○ ○ ○ ○ ○
08-23
Mechanical Gear A
at Reel
1-65535 100
○ ○ ○ ○ ○
08-24
Mechanical Gear B
at Motor
1-65535 100
○ ○ ○ ○ ○
08-29
Proportional Gain 1
of Tension PID P
0.0~1000.0 50.0
○ ○ ○ ○
08-30
Integral Time of
Tension PID I
0.00~500.00 sec 1.00
○ ○ ○ ○
08-32
Proportional Gain 2
of Tension PID P
0.0~1000.0 50.0
○ ○ ○ ○
08-33
Integral Time 2 of
Tension PID I
0.00~500.00 sec 1.00
○ ○ ○ ○
08-36
Tension/Line Speed
PID Output Limit
0~100.00%
20.00
○ ○ ○ ○
08-40
Pulse Number for
Each Meter
0.0~6000.0 pulse/m
0.0
○ ○ ○ ○ ○
08-41
Current Line Speed 0.0~3000.0m/min 0.0
○ ○ ○ ○ ○
08-46
Initial Reel Diameter
0.0~6000.0mm
1.0
○ ○ ○ ○ ○
08-47
Initial Reel Diameter 1
0.0~6000.0mm
1.0
○ ○ ○ ○ ○
08-48
Initial Reel Diameter 2
0.0~6000.0mm
1.0
○ ○ ○ ○ ○
08-55
Smart Start Function
0: Disable
1: Enable
2: In unwind mode, rewind in reverse direction
1
○ ○ ○ ○
08-61
Allowance
Difference of Reel
Diameter of Broken
Belt Detection
1.0~6000.0mm 100.0
○ ○ ○ ○
08-64
Allowance Error
Detection Time of
Tension/Line Speed
PID Feedback
0.0~10.0 sec 0.5
○ ○ ○ ○
08-65
Error Treatment of
Tension/Line Speed
PID Feedback
0: Warn and keep operation
1: Warn and coast to stop
2: Warn and ramp to stop
0
○ ○ ○ ○
Group 9 Communication Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
09-22
Display Digital Value
of Analog Output 2
0~4095 Read-
only
○ ○ ○ ○ ○
09-23
Display Digital Value
of Analog Output 3
0~4095 Read-
only
○ ○ ○ ○ ○
