Chapter 4 Parameters
4-29
Group 11 Advanced Parameters
In version 2.02, the parameters are from Pr.11-00 to Pr.11-30.
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
11-09
Level of Phase-loss
0.0~320.0 60.0
○ ○ ○ ○ ○
11-10
Reserved
11-18
|
11-28
Reserved
11-29
Accumulative Operation Time of Phase-
loss
0~65535 (hour) 0 ○ ○ ○ ○ ○
11-30
APR Curve Time 0.00~655.35 sec 3.00
○
4.2.2 Version 2.04
New or update parameter groups are:
Group 0 System Parameters
Group 2: Digital Input/Output Parameters
Group 3: Analog Input/Output Parameters
Group 5: Motor Parameters
Group 6: Protection Parameters
Group 8: High-function PID Parameters
Group 10: Speed Feedback Control Parameters
Version 2.04
Group 0 System Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
00-03
Start-up Display Selection
0: Display the frequency command value (LED F)
1: Display the actual output frequency (LED H)
2: Multifunction display, see Pr.00-04 (LED U)
3: Display the output current (A)
0
○ ○ ○ ○ ○
00-04
Content of Multi Function
Display
0: Display output current (A)
1: Display counter value (C)
2: Display output frequency (H)
3: Display DC-BUS voltage (
u
)
4: Display output voltage (E)
5: Output power factor angle (n)
6: Display output power (kW)
7: Display actual motor speed (HU)
8: Display estimate output torque (kg-m)
9: Display PG position (G) (refer to Pr.10-00 and Pr.10-
01)
10: Display PID feedback
11: Display AVI (%)
12: Display ACI (%)
13: Display AUI (%)
14: Display the temperature of heat sink (°C)
15: Display the temperature of IGBT (°C)
16: The status of digital input (ON/OFF)
17: The status of digital output (ON/OFF)
18: Multi-step speed
19: The corresponding CPU pin status of digital input
20: The corresponding CPU pin status of digital output
21: Number of actual motor revolution (PG1 of PG
card)
22: Pulse input frequency (PG2 of PG card)
23: Pulse input position (PG2 of PG card)
0
○ ○ ○ ○ ○
Group 2 Digital Input/Output Parameters
New settings 44~50 for Pr.02-00~Pr.02-06 and new parameter 02-43.
