Delta VFD-VE - Appendix A Specifications

Revision Apr. 2016, 07VE, SW V2.05 A-1
Appendix A Specifications
Voltage Class 230V Class
Model Number VFD-XXXV 007 015 022 037 055 075 110 150 185 220 300 370
Max. Applicable Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Max. Applicable Motor Output (hp) 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50
Output Rating
Rated Output Capacity (kVA)
1.9 2.7 4.2 6.5 9.5 13 19 25 29 34 46 55
Rated Output Current for
Constant Torque (A)
5.0 7.5 11 17 25 33 49 65 75 90 120 146
Rated Output Current for
Variable Torque (A)
6.25 9.4 13 21 31 41 61 81 93 112 150 182
Maximum Output Voltage (V) 3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.00~600.00 Hz
Carrier Frequency (kHz)
15 9 6
Input Rating
Rated Input Current (A)
6.4 9.9 15 21 25 33 52 63 68 79 106 126
Rated Voltage/Frequency
3-phase
200-240V, 50/60Hz
Voltage Tolerance

10%(180~264 V)
Frequency Tolerance

5%(47~63 Hz)
Cooling Method
Natural
Fan Cooled
Weight (kg) 2.7 3.2 4.5 6.8 8 10 13 13 13 13 36 36
Voltage Class 460V Class
Model Number VFD-XXXV 007 015 022 037 055 075 110 150 185 220 300 370 450 550 750
Max. Applicable Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Max. Applicable Motor Output
(hp)
1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50 60 75 100
Output Rating
Rated Output Capacity (kVA) 2.3 3.2 4.2 6.3 9.9 14 18 24 29 34 46 56 69 80 100
Rated Output Current for
Constant Torque (A)
3.0 4.2 6.0 8.5 13 18 24 32 38 45 60 73 91 110 150
Rated Output Current for
Variable Torque (A)
3.8 5.3 7.5 10 16 22 30 40 47 56 75 91 113 138 188
Maximum Output Voltage (V) 3-phase Proportional to Input Voltage
Output Frequency (Hz) 0.00~600.00 Hz
Carrier Frequency (kHz) 15 9 6
Input Rating
Rated Input Current (A)
3-phase
380~480V
4.0 5.8 7.4 9.9 12 17 25 27 35 42 56 67 87 101 122
Rated Voltage 3-phase 380 to 480 V
Voltage Tolerance

10%(342~528 V)
Frequency Tolerance

5%(47~63 Hz)
Cooling Method
Natural
Fan Cooled
Weight (kg) 2.7 3.2 4.5 6.8 8 10 13 13 13 13 36 36 36 50 50
