Chapter 4 Parameters
4-74
status of bit 8-15 of Pr.02-10 to ON or OFF by KPV-CE01 or communication.
Summary of function settings (Take the normally open contact for example, ON: contact
is closed, OFF: contact is open)
Settings Functions Descriptions
0 No Function
1
Multi-step speed
command 1/multi-step
position command 1
15 step speeds could be conducted through the digital statuses
of the 4 terminals, and 17 in total if the master speed and JOG
are included. (Refer to Pr. 04-00~04-29)
2
Multi-step speed
command 2/ multi-step
position command 2
3
Multi-step speed
command 3/ multi-step
position command 3
4
Multi-step speed
command 4/ multi-step
position command 4
5 Reset
After the error of the drive is eliminated, use this terminal to
reset the drive.
6 JOG Command JOG operation
7
Acceleration/deceleration
Speed Inhibit
When this function is enabled, acceleration and deceleration is
stopped and the AC motor drive start to accel./decel. from the
inhibit point.
8
The 1
st
, 2
nd
acceleration
or deceleration time
selection
The acceleration/deceleration time of the drive could be
selected from this function or the digital statuses of the
terminals; there are 4 acceleration/deceleration speeds in total
for selection.
9
The 3
rd
, 4
th
acceleration
or deceleration time
selection
10 EF Input External fault input terminal
11 B.B. Input
When this contact is ON, output of the drive will be cut off
immediately, and the motor will be free run and display B.B.
signal. Refer to Pr.07-08 for details.
12 Output Stop
If this contact is ON, output of the drive will be cut off
immediately, and the motor will then be free run. And once it is
turned to OFF, the drive will accelerate to the setting frequency.
13
Cancel the setting of the
optimal accel./decel. time
Before using this function, Pr.00-13 should be set to 01/02/03/04
first. When this function is enabled, OFF is for auto mode and
