Chapter 4 Parameters
4-75
Settings Functions Descriptions
ON is for linear accel./decel.
14
Switch between drive
settings 1 and 2
When the contact is ON: use the motor 2 parameters. OFF: use
the motor 1 parameters.
15
Operation speed
command form AVI
When the contact is ON, the source of the frequency will force to
be AVI. (If the operation speed commands are set to AVI, ACI
and AUI at the same time. The priority is AVI
＞
ACI
＞
AUI)
16
Operation speed
command form ACI
When the contact is ON, the source of the frequency will force to
be ACI. (If the operation speed commands are set to AVI, ACI
and AUI at the same time. The priority is AVI
＞
ACI
＞
AUI)
17
Operation speed
command form AUI
When this function is enabled, the source of the frequency will
force to be AUI. (If the operation speed commands are set to
AVI, ACI and AUI at the same time. The priority is AVI
＞
ACI
＞
AUI)
18 Emergency Stop (07-36)
When the contact is ON, the drive will ramp to stop by Pr.07-36
setting.
19 Digital Up command When the contact is ON, the frequency will be increased and
decreased. If this function keeps ON, the frequency will be
increased/decreased by Pr.02-07/Pr.02-08.
20 Digital Down command
21 PID function disabled When the contact is ON, the PID function is disabled.
22 Clear counter
When the contact is ON, it will clear current counter value and
display “0”. Only when this function is disabled, it will keep
counting upward.
23
Input the counter value
(multi-function input
command 6)
The counter value will increase 1 once the contact is ON. It
needs to be used with Pr.02-16.
24 FWD JOG command
When the contact is ON, the drive will execute forward Jog
command.
25 REV JOG command
When the contact is ON the drive will execute reverse Jog
command.
26
TQCPG/FOCPG mode
selection
When the contact is ON: TQCPG mode.
When the contact is OFF: FOCPG mode.
