Chapter 4 Parameters
4-41
Group 3 Analog Input/Output Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
03-18
Analog Output 1
0: Output frequency (Hz)
0
○ ○ ○ ○ ○
1: Frequency command (Hz)
○ ○ ○ ○ ○
03-21
Analog Output 2
2: Motor speed (Hz)
○ ○ ○ ○ ○
3: Output current (rms)
○ ○ ○ ○ ○
03-24
Analog Output 3
4: Output voltage
○ ○ ○ ○ ○
5: DC Bus Voltage
○ ○ ○ ○ ○
6: Power factor
○ ○ ○ ○ ○
7: Power
○ ○ ○ ○ ○
8: Output torque
○ ○ ○ ○ ○
9: AVI
○ ○ ○ ○ ○
10: ACI
○ ○ ○ ○ ○
11: AUI
○ ○ ○ ○ ○
12: q-axis current
○ ○ ○ ○ ○
13: q-axis feedback value
○ ○ ○ ○ ○
14: d-axis current
○ ○ ○ ○ ○
15: d-axis feedback value
○ ○ ○ ○ ○
16: q-axis voltage
○ ○ ○ ○ ○
17: d-axis voltage
○ ○ ○ ○ ○
18: Torque command
○ ○ ○ ○ ○
19: Pulse frequency command
○ ○ ○ ○ ○
03-19
Gain for Analog
Output 1
0~200.0% 100.0
○ ○ ○ ○ ○
03-20
Analog Output 1
Value in REV
Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-22
Gain for Analog
Output 2
0~200.0% 100.0
○ ○ ○ ○ ○
03-23
Analog Output 2
Value in REV
Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-25
Gain for Analog
Output 3
0~200.0% 100.0
○ ○ ○ ○ ○
03-26
Analog Output 3
Value in REV
Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
Group 5 Motor Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
05-01
Full-load Current of
Motor 1 (A)
40-120% of drive’s rated current
#.##
○ ○ ○ ○ ○
05-02
Rated power of Motor 1
(kW)
0~655.35 #.##
○ ○ ○
05-06
Stator Resistance (Rs)
of Motor 1
0~65.535
#.###
○ ○ ○
05-07
Rotor Resistance (R
r
)
of Motor 1
0~65.535
#.###
○ ○ ○
05-08 Magnetizing Inductance
(Lm) of Motor 1
0~6553.5mH #.#
○ ○ ○
05-09
Stator inductance (Lx)
of Motor 1
0~6553.5mH #.#
○ ○ ○
05-13
Full-load Current of
Motor 2 (A)
40-120% #.##
○ ○ ○ ○ ○
05-14
Rated Power o
f
Motor 2
(kW)
0~655.35 #.##
○ ○ ○
05-17
No-load Current of
Motor 2 (A)
0- factory setting of Pr.05-01 #.##
○ ○ ○ ○
05-18
Stator Resistance(Rs)
of Motor 2
0~65.535
#.###
○ ○ ○
05-19
Rotor Resistance(Rr) of
Motor 2
0~65.535
#.###
○ ○ ○
05-20 Magnetizing Inductance
(Lm) of Motor 2
0~6553.5mH #.#
○ ○ ○
