Delta VFD-VE - Integral Time 2 of Tension PID I; PID Output Status; Tension;Line Speed PID Output Limit; Source of Line Speed Input Command

Chapter 4 Parameters
4-147
08-33  Integral Time 2 of Tension PID I Unit: 0.01
Control
mode
VF VFPG SVC FOCPG
Factory Setting: 1.00
Settings 0.00 to 500.00 sec
08-34 Reserved
08-35 PID Output Status
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 0
Settings 0 Positive output
1 Negative output
 Please select the applicable method by the different requirements from the following
table.
0 ~ 100% 0 ~ 100%
T ens ion f eedback
Rewind
Unwind
loose
loose
tight
tight
positive output
negative output
positive output
negativ e output
08-36 Tension/Line Speed PID Output Limit Unit: 0.01
Control
mode
VF VFPG SVC FOCPG
Factory Setting: 20.00
Settings 0 to 100.00%
 Output limit range=Pr.08-36 * Pr.01-00.
08-37 Source of Line Speed Input Command
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 0
Settings 0 Disable
1 Analog input (Pr. 03-00~03-02 is set to 12 line speed)
2 RS-485 communication setting (Pr.08-41)
3 Pulse input (Pr.08-40)
4 DFM-DCM pulse input (Pr.02-18)
