Chapter 4 Parameters
4-155
08-66 Upper Limit of Tension PID Feedback Unit: 0.1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 100.0
Settings 0.0~100.0%
08-67 Lower Limit of Tension PID Feedback Unit: 0.1
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 0.0
Settings 0.0~100.0%
 It is valid when Pr.08-21 is set to 1.
08-68 Reserved
08-69 DFM Selection
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 0
Settings 0 Output frequency
1 Frequency command
08-70  Low-pass Filter Time of Line Speed Unit: 0.01
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory Setting: 0.00
Settings 0.00~100.00 sec
 It is used to suppress the oscillation of line speed.
08-71
|
08-75
Reserved
08-76 Source of Tension Setting
Control
mode
TQCPG
Factory Setting: 0
Settings 0 Communication RS-485 (Pr.08-78)
1 Analog input (Pr. 03-00~03-02 is set to 15 tension setting) (Pr.08-78)
 Pr.08-76~08-86 are valid when Pr.08-21 is set to 4.
 When Pr.08-76 is set to 0, Pr.08-78 setting can be changed by inputting the digital
keypad, HMI page plan or text panel(PLC product: TP series) via communication.
 When Pr.08-76 is set to 1 and one of Pr.03-00~03-02 is set to 15, Pr.08-78 will display the
tension setting.
