Delta VFD-VE - Page 61

Chapter 4 Parameters
4-10
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQCPG
9: AVI
○ ○ ○ ○ ○
10: ACI
○ ○ ○ ○ ○
11: AUI
○ ○ ○ ○ ○
12: q-axis current
○ ○ ○ ○ ○
13: q-axis feedback value
○ ○ ○ ○ ○
14: d-axis current
○ ○ ○ ○ ○
15: d-axis feedback value
○ ○ ○ ○ ○
16: q-axis voltage
○ ○ ○ ○ ○
17: d-axis voltage
○ ○ ○ ○ ○
18: Torque command
○ ○ ○ ○ ○
19: Pulse frequency command
○ ○ ○ ○ ○
03-19
Gain for
A
nalog Output
1
0~200.0% 100.0
○ ○ ○ ○ ○
03-20
Analog Output 1 Value
in REV Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-22
Gain for
A
nalog Output
2
0~200.0% 100.0
○ ○ ○ ○ ○
03-23
Analog Output 2 Value
in REV Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-25
Gain for Analog Output
3
0~200.0% 100.0
○ ○ ○ ○ ○
03-26
Analog Output 3 Value
in REV Direction
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
